The Victory RIP XV Elite is built for bowhunters and archers who want one thing above almost everything else: speed. With an extremely low-GPI .204" small-diameter carbon shaft, Elite ±.001" straightness, digital spine alignment, and Victory’s ICE Nano Ceramic coating, the RIP XV gives you room to build a fast, flat-shooting arrow without giving up the component flexibility of a 5mm-class hunting platform.
The RIP XV is the lightest shaft in Victory’s RIP hunting-arrow family. That makes it especially useful for shorter draw lengths, lower draw weights, long-range shooting, or anyone trying to preserve trajectory while still having room to add front-end component weight.
Key Features
Extremely Low-GPI .204" Shaft
The RIP XV uses Victory’s .204" small-diameter platform with an exceptionally lightweight carbon construction. The reduced shaft diameter limits the amount of surface area exposed to crosswind, while the low GPI helps preserve arrow speed and flatten trajectory.
Elite ±.001" Straightness
The Elite version of the RIP XV carries Victory’s tightest ±.001" straightness specification for shooters who want the premium grade of the platform.
Digitally Spine Aligned
Victory digitally identifies and marks the spine orientation of each shaft at the factory. That gives the arrow builder a repeatable reference when orienting nocks and vanes during assembly.
Weight Matched Within ±0.5 Grains Per Dozen
Victory weight matches each dozen RIP XV shafts within ±0.5 grains, helping reduce arrow-to-arrow weight variation when building a matched set.
ICE Nano Ceramic Coating
The RIP XV uses Victory’s ICE Nano Ceramic coating to create a very slick exterior surface. One of the most noticeable practical benefits is easier arrow removal from dense foam targets.
21-Grain Aluminum SHOK™ Insert Included
The RIP XV includes Victory’s lightweight 21-grain aluminum SHOK™ insert. The component sleeves over the front of the shaft for additional protection while accepting standard 8-32 threaded broadheads and field points.
The light stock component complements what the RIP XV is designed to do: keep total arrow weight down and give the shooter room to decide how much additional front-end weight to add.
Multiple Front-End Weight Options
Victory offers several optional components for the .204" platform, including 50-grain aluminum, 60-grain stainless steel, and heavier stainless SHOK™ options, along with .204 backweights.
That gives you a lot of freedom to manipulate finished arrow weight and FOC, but adding significant front-end weight also dynamically weakens the shaft. Spine, arrow length, draw weight, and the complete component package should always be considered together.
8-Grain .204 Nock Included
Victory includes an 8-grain .204 nock designed around the RIP XV’s small-diameter platform.
Who It's Built For
The Victory RIP XV Elite makes the most sense for shooters who need to keep shaft weight low.
It is especially useful for shorter draw lengths and lower draw weights. Those shooters do not have as much available energy to work with, so starting with a heavy shaft can quickly produce a finished arrow that is slower than necessary. The RIP XV leaves more room to add a broadhead, insert weight, vanes, and other components while keeping overall weight practical.
It can also work very well for speed-focused 3D shooting, Total Archery Challenge-style events, western hunting, and other applications where flatter trajectory and tighter pin gaps are valuable.
Higher-poundage or longer-draw shooters can use the same low-GPI platform to build an extremely fast arrow, or use the available component weight to shift more of the finished arrow mass toward the front.
The important tradeoff is durability. The RIP XV is intentionally built extremely light. If maximum shaft durability is a higher priority than minimum GPI, we generally look toward the Victory HLR or RIP TKO instead.
Specifications
Spine Specifications
| Spine |
GPI |
| 250 |
8.0 |
| 300 |
7.1 |
| 350 |
6.4 |
| 400 |
5.9 |
| 500 |
5.1 |
General Specifications
| Specification |
Detail |
| Brand |
Victory Archery |
| Model |
RIP XV Elite |
| Construction |
100% high-modulus carbon |
| Internal Diameter |
.204" / 5mm class |
| Straightness Specification |
±.001" Elite / V1 |
| Weight Matching |
±0.5 grains per dozen |
| Spine Alignment |
Digitally spine aligned and marked |
| Coating |
ICE Nano Ceramic |
| Included Insert |
21-grain aluminum SHOK™ insert |
| Thread Standard |
8-32 |
| Nock |
.204 nock |
| Nock Weight |
8 grains |
| Configuration |
Bare shaft / unfletched |
| Sold |
Individually |
Our Take on the Victory RIP XV Elite
The RIP XV has a very specific purpose in our arrow lineup: it gives us an extremely low-GPI 5mm shaft when keeping finished arrow weight and maintaining speed are major priorities.
That becomes especially useful with shorter draw lengths and lower draw weights. Those shooters can run out of room quickly with a heavy shaft. By the time you add the insert, broadhead, vanes, nock, and potentially a wrap, finished arrow weight can climb faster than you want it to.
The RIP XV solves that problem by starting extremely light. In a 400 spine, for example, the shaft is only 5.9 grains per inch. That gives us a lot of freedom to put weight back into the arrow through the component system rather than having most of the weight locked into the shaft itself.
That does not mean we automatically recommend loading the front of the arrow with as much weight as possible. Adding front-end weight changes finished arrow weight, FOC, and dynamic spine. The goal is still to build the complete arrow around the shooter rather than chase one number.
The tradeoff is durability. In our experience, the RIP XV is not as durable as the Victory HLR, and the RIP TKO is the most durable of the three. That makes sense when you look at what each shaft is designed to accomplish. The XV is chasing minimum GPI and speed; the TKO gives up some of that weight advantage for a more substantial shaft wall.
That does not make the RIP XV a bad hunting arrow. It means you need to choose it for the right reason. If you need extremely low GPI, want to preserve trajectory, or have a shorter draw length or lower draw weight that makes a heavier shaft difficult to work with, the XV can be an excellent solution.
If you have plenty of draw length and draw weight and your priority is maximum durability, we are more likely to move you toward an HLR or RIP TKO.
We also like the ICE coating and factory spine alignment. The coating makes these arrows noticeably easier to pull from dense foam, while the spine marking gives us a consistent reference when building a matched set.
Extreme Outfitters sells these shafts individually, so you can test the RIP XV before committing to a full dozen. Free cut and glue is also available with your arrow purchase.
Frequently Asked Questions
What does RIP XV stand for?
XV stands for Xtreme Velocity. The RIP XV is Victory’s lightweight .204" hunting platform designed around low GPI, high arrow speed, and flatter trajectory.
What is the straightness specification of the RIP XV Elite?
The Victory RIP XV Elite carries a ±.001" Elite / V1 straightness specification.
What insert comes with the Victory RIP XV?
The current RIP XV includes Victory’s 21-grain aluminum SHOK™ insert. It accepts standard 8-32 threaded broadheads and field points.
Can I add a heavier insert to the RIP XV?
Yes. Victory offers multiple optional .204" SHOK™ components, including heavier aluminum and stainless-steel configurations, as well as backweights.
Keep in mind that adding front-end weight increases finished arrow weight and dynamically weakens the shaft, so component changes should always be considered together with spine and arrow length.
Is the Victory RIP XV good for hunting?
Yes, when its strengths match the shooter. The RIP XV makes the most sense when low shaft weight, speed, and trajectory are priorities. It can be especially useful for shorter draw lengths, lower draw weights, or hunters who intentionally want a lightweight 5mm setup.
Is the RIP XV durable?
The RIP XV is a hunting shaft, but its extremely low GPI comes with a tradeoff. In our experience, it is less durable than heavier Victory 5mm shafts such as the HLR and RIP TKO. If maximum durability is your first priority, we would generally move toward one of those heavier platforms.
What is the difference between the Victory RIP XV and HLR?
The RIP XV is the lighter, more speed-focused option. The Victory HLR Elite carries more shaft weight but gives us a stronger balance between low GPI and durability.
We generally look at the RIP XV when minimum shaft weight is important and the HLR when we want to retain much of that build flexibility while moving into a more durable shaft.
What is the difference between the RIP XV and RIP TKO?
The RIP XV prioritizes low GPI and speed. The Victory RIP TKO Elite carries more shaft weight and is the more durability-focused option.
For a shooter with plenty of draw length and draw weight who wants a robust hunting arrow, we generally lean toward the RIP TKO. For a shorter-draw or lower-poundage shooter who needs to control finished weight, the RIP XV can make much more sense.
Who benefits most from the RIP XV?
Shorter-draw and lower-poundage shooters are some of the best candidates because the low GPI gives them more freedom to add normal hunting components without producing an excessively heavy finished arrow. Speed-focused shooters and archers who value flatter trajectory can benefit from the same design.
Does the RIP XV use standard broadheads?
Yes. Victory’s SHOK™ system accepts standard 8-32 threaded broadheads and field points.
What does factory spine alignment mean?
Victory digitally identifies the shaft’s spine orientation and marks it at the factory. That gives the arrow builder a consistent reference when orienting the nock and vanes.
What does the ICE Nano Ceramic coating do?
The ICE coating creates a very slick exterior surface. One of the most noticeable practical benefits is easier arrow removal from dense foam targets.
Can Extreme Outfitters cut and build RIP XV arrows?
Yes. Free cut and glue is available with your arrow purchase. If you need help determining whether the XV is appropriate for your draw length, draw weight, finished-arrow target, or desired spine, our archery team can help you plan the complete build.
RIP XV, HLR, or RIP TKO?
Victory’s three .204" hunting platforms cover very different priorities. The RIP XV is the lightest and most speed-focused. The Victory HLR Elite sits in the middle, balancing relatively low GPI with additional durability. The Victory RIP TKO Elite carries more shaft weight but is our choice when durability is the higher priority.
There is no automatically better option. The right shaft depends on draw length, draw weight, desired finished-arrow weight, trajectory, and how much durability your application demands.
Learn More About the Victory RIP XV
We have spent a lot of time testing and building with the RIP XV. For a deeper look at the shaft and the reasoning behind where we use it, check out our Extreme Outfitters RIP XV resources.
